Huawei Switch S110-24LP2SR

Key Specifications

• Chassis Height: 1 U
• Chassis Material: Metal
• Typical Power Consumption: 24 W
• Maximum Power Consumption:
  • Without PoE: 24 W
  • Full PoE Load: 165 W (PoE: 124 W)
• Static Power Consumption: 13 W
• Uplink Ports: 2 x GE SFP ports
• Downlink Ports: 24 x 10/100/1000BASE-T ports (124 W PoE+)
• Working Mode: Standard mode, Port isolation, Uplink aggregation, Flow control disabling
• MAC Address Entry: 8K
• Ingress Protection Level: IP20 (dustproof/waterproof)

Product Features

• 24 Gigabit Ethernet Ports with PoE+: Equipped with 24 auto-negotiating 10/100/1000 Mbps RJ-45 ports supporting IEEE 802.3af/at PoE+, with a total PoE power budget of 124W for powering IP phones, cameras, and access points.
• 2 Gigabit SFP Uplink Ports: Provides fiber uplink options through 2 dedicated GE SFP ports for long-distance, high-speed data transmission between switches or core networks.
• Energy Efficient Ethernet (EEE): Incorporates IEEE 802.3az to reduce power consumption during low traffic periods without compromising network performance.
• Fanless, Silent Design: Completely silent operation with natural heat dissipation and no moving parts—ideal for office environments where noise is a concern.
• Advanced Reliability and Protection: Includes storm control, uplink aggregation, port isolation, and surge protection up to ±6 kV on the power supply and ±4 kV on service ports for stable operation.
• Plug-and-Play Setup: Designed for rapid deployment with no configuration required, simplifying network expansion for IT teams and small businesses.

Advantages of Huawei S110-24LP2SR

• High Performance: Equipped with 24 Ethernet ports, the Huawei Switch S110-24LP2SR ensures high-speed data transfer, making it ideal for bandwidth-intensive applications such as video conferencing, VoIP, and cloud computing.
• Power-over-Ethernet (PoE) Support: This switch supports PoE, enabling you to power devices like IP cameras, wireless access points, and VoIP phones directly through the Ethernet cables, eliminating the need for additional power sources.
• Energy-Efficient Design: Designed with energy efficiency in mind, the S110-24LP2SR minimizes power consumption without compromising performance, helping businesses reduce their overall energy costs.
• Easy Management: The switch offers simple and intuitive management features, allowing network administrators to monitor and control the network easily. This reduces the complexity of network management and helps in maintaining optimal network performance.
• Scalability: As your business grows, so does your network. The Huawei Switch S110-24LP2SR supports seamless scalability, enabling you to expand your network infrastructure without compromising on speed or efficiency.
• Applications:
  • Small to Medium-Sized Businesses: Ideal for SMBs looking to optimize their network infrastructure with a cost-effective yet powerful switch.
  • Educational Institutions: Perfect for schools and universities requiring reliable and scalable network solutions.
  • Retail and Hospitality: Provides a seamless network experience for customer service, POS systems, and security systems.
• Compliance and Certification
  • EMC Certification
  • Safety Certification
  • Manufacturing Certification

Common Applications

• IP Surveillance Systems: Powers IP cameras directly via Ethernet, simplifying cabling and installation.
• VoIP Deployments: Supports PoE phones without separate power adapters.
• Wireless Access Points: Ideal for powering APs in office or campus environments.
• Small Business Networks: Provides reliable gigabit connectivity with centralized power management.
• Retail & Hospitality: Supports POS systems, digital signage, and guest Wi-Fi infrastructure.
