Specifications
Host Bus Interface PCIe 3.0 x8
Bracket Height Low-profile and full-height
Size (Height x Width x Depth) 69 mm x 168 mm x 17.3 mm
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Warranty 5 years1
E25G21-F2-2021-ENU-REV001
Network
IEEE Specification Compliance
• IEEE 802.3ae 10Gbps Ethernet
• IEEE 802.3by 25Gbps Ethernet
• IEEE 802.3ad Link Aggregation
Connector SFP28
Data Transfer Rates 25 Gbps/10 Gbps
Network Operation mode Full Duplex
Supported Features
• Auto-negotiation between 10Gb/s and 25Gb/s
• Support for 1.5 to 9 KB Jumbo Frames
• Offloaded storage over Ethernet
• Non-offloaded storage over Ethernet
• TCP/UDP Checksum Offloading
• Large Send Offload (LSO)
• Generic Receive Offload (GRO)
• Generic Segmentation Offload (GSO)
• TCP Segmentation Offload (TSO)
• Receive Side Scaling (RSS)
• Transmit Side Scaling (TSS)
