Aruba Instant On 1930 48G CL4 PoE 4SFP+ 370W Switch

DifferentiatorPorts: 48 Gigabit copper
Uplink ports: 4 SFP+ 1/10 GbE ports

Power consumption520W maximum, 50W idle

Input voltage100 – 127 / 200 – 240 VAC

Ports48 RJ-45 autosensing 10/100/1000 Class
4 PoE ports
(IEEE 802.3 Type 10B ASE-T, IEEE 802.3u Type 100 BASE-TX, IEEE 802.3ab Type 1000 BASE-T)

Duplex: 10 BASE-T/100 BASE-TX: half or
full; 1000 BASE-T: full only
4 SFP+ 1/10 GbE ports

Switching capacity176 Gbps

Throughput130.95 Mpps, maximum

Memory and processorARM Cortex-A9 @ 800 MHz
512 MB SDRAM, 256 MB flash
1.5 MB packet buffer

PoE capability370 W Class 4

Operating temperature32°F to 104°F (0°C to 40°C)

Management featuresInstant On Portal, Web browser, SNMP Manager

WarrantyLimited lifetime warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty duration.
Community support is available for the life of the product.

Detailed product descriptionThe HPE Networking Instant On Switch Series 1930 empowers you to do more. Affordable and easy-to-deploy, these smart-managed, fixed-configuration Gigabit switches are designed for the today bandwidth-heavy applications.

Weight4.59 kg (10.12 lb)

Dimensions4.39 x 44.25 x 32.26 cm (1.73 x 17.42 x 12.7 in)

Description
Reviews (0)

Aruba Instant On 1930 48G CL4 PoE 4SFP+ 370W Switch

The Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 370W Switch (JL684A) is a high-performance, smart-managed switch designed for small and growing businesses. It offers 24 Gigabit Ethernet ports with Class 4 PoE support, providing up to 370W of total PoE power to efficiently power devices such as IP cameras, access points, and VoIP phones. Buy Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 370W Switch at affordable prices at Synology Kenya.

Overview

The Aruba Instant On 1930 switch series is designed for small and growing businesses that require enhanced performance to support bandwidthdemanding applications. The Aruba Instant On 1930 switch series seamlessly integrates with existing
Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely.

These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1G SFP slots on 8-port model and 1G/10G SFP+ slots on 24-/48G models for fiber connectivity.

About this item

The Aruba Instant On 1930 24G Class 4 PoE 4SFP/SFP+ 370W Switch is a high performance, smart managed switch designed for small and medium businesses – fast set-up, easy management, security you can trust.
Two-Factor Authentication enabled
Configuration: Rack-width design with rack mounting ears. Or place desktop or flat surface. Ports and LEDs facing the front – #ABA w/ internal power supply and US-syle plug.
Management: Simplified cloud management from app or web browser with no recurring cost – The Aruba Instant On mobile app allows you to set up, manage, and monitor Instant On switches and Access Points directly from your phone, from anywhere. Guided step-by-step instructions to install devices to get your network up and running quickly – no technical expertise required. Alternative integrated traditional full local web interface for advanced configuration with static routing, ACLs, SNMP.
Ports: 28 active ports | 24x Gigabit 10/100/1000 + 4x Gigabit / 10G SFP+ slots| Power over Ethernet: PoE / PoE+ (Class 4) on 24 ports | PoE power budget 370 Watts | High-performance future-proof switch
