Aruba 10G SFP+ LC SR 300m MMF XCVR

HPE Aruba Networking J9150D 10G SFP+ LC SR 300m OM3 MMF Transceiver

Description

The Aruba 10G SFP+ LC SR 300m MMF Transceiver (model J9150D) is a high-performance, hot-pluggable optical module designed for short-range data transmission over multimode fiber. It supports data rates up to 10.31 Gbps and operates at an 850 nm wavelength, enabling connectivity up to 300 meters on OM3 fiber and 400 meters on OM4 fiber.

Technical Specifications

• Type: SFP+ Transceiver Module
• Form Factor: SFP+ (Small Form-factor Pluggable Plus)
• Data Rate: 1.25 to 10.31 Gbps
• Wavelength: 850 nm (Tx/Rx)
• Optical Budget: 4.6 dB
• Max Distance:
  • 300 meters over OM3 fiber
  • 400 meters over OM4 fiber
• Connector Type: LC duplex
• Media Type: Multi-Mode Fiber (MMF)
• Temperature Range: 0°C to 70°C
• Protocol Support: 10GBASE-SR Ethernet
• Compatibility: Designed for use with HPE Aruba switches and networking equipment

Key Benefits

• Enhanced connectivity

  The HPE Aruba SFP+ transceiver module offers a high-speed 10 Gigabit Ethernet connection that ensures rapid data transfer rates of up to 10 Gbps, making it suitable for high-bandwidth applications.

• Broad compatibility

  Featuring an LC multi-mode connector, this transceiver module is designed to facilitate seamless integration with a wide range of networking equipment, ensuring a flexible solution for your connectivity needs.

• Extended reach

  With a maximum transfer distance of 300 m, the HPE Aruba SFP+ transceiver module is perfect for extending your network reach, making it suitable for a variety of enterprise environments.

• Performance

  • 10 Gigabit Ethernet Support: Enables high-speed data transfer up to 10 Gbps, ideal for bandwidth-intensive applications.
  • Multi-Mode Fiber (MMF): Designed for OM3 MMF cabling, supporting distances up to 300 meters, which is suitable for most data center and enterprise deployments.
  • SFP+ Form Factor: Compact and hot-swappable, allowing easy integration into Aruba switches and other compatible networking equipment

• Reliability & Efficiency

  • Low Latency: Optimized for fast transmission with minimal delay, crucial for real-time applications like video conferencing and cloud computing.
  • Energy Efficient: Consumes less power compared to older transceiver models, contributing to lower operational costs.

• Flexibility & Scalability

  • Plug-and-Play Installation: Simplifies deployment and upgrades without requiring system downtime.
  • Scalable Architecture: Supports growing network demands, making it a future-proof choice for expanding infrastructures.

  Quality & Support

  • Manufacturer Warranty: Comes with a warranty from HPE Aruba, ensuring product reliability and support.
  • Broad Compatibility: Works with Aruba Instant On switches and other HPE networking gear, enhancing interoperability

Ideal Use Cases

• Data Centers: Perfect for connecting servers, switches, and storage within racks or across nearby racks. Its 300m range on OM3 fiber suits typical intra-data center distances.
• Enterprise Networks: Useful for backbone connections between core switches and aggregation switches in large office buildings or campuses.
• Campus Environments: Supports high-speed links between buildings or network closets where multimode fiber is already deployed.
• Network Upgrades: Ideal for upgrading existing 1G links to 10G in environments with OM3 or OM4 multimode fiber without replacing cabling.
• Aruba Instant On Deployments: Compatible with Aruba Instant On switches, making it a plug-and-play option for small to medium businesses seeking reliable 10G connectivity
